FS4 Frame Synchronizer/Converter v1.1
• 4 x 3G-SDI outputs, 4 x fiber or HD-BNC (optional SFP modules)
• SFP fiber modules, 3G-SDI, Dual LC, Dual LC CWDM, Single LC, or Single SC, SMPTE-
297
• SFP fiber module, 12G/6G-SDI, dual LC, SMPTE-297
• SFP coax module, 12G/6G-SDI, dual HD-BNC
• 12G/6G/3G/HD/SD, SMPTE-259/292/424/2081/2082
• Single Link 12G/6G-SDI (with optional SFP module)
• Quad Link 3G-SDI Level A or B-DL (4 x 3G), SMPTE-425-5
• Dual Link 3G-SDI Level B-DS (2 x 3G), SMPTE-425-3
• Single Link 3G-SDI Level A, B-DL, or B-DS, SMPTE 425
• Quad Link HD-SDI (4 x 1.5G)
• Dual Link HD-SDI (2 x 1.5G), SMPTE-372
•Single Link HD/SD
• Quadrant (Square Division) or 2SI (Two Sample Interleave) 4K/UltraHD output pixel
mapping
Monitor Output Digital
• 1 x BNC, 1 x 3G-SDI output
• 3G-SDI/HD/SD, SMPTE-259/292/424, 10-bits
• 1 x HDMI, 1 x HD output
•2K/HD/SD, HDMI v1.4a
• Monitored Video Processor output (video and audio) is simultaneously output on both
connectors
• 4K/UltraHD down-converted to 2K/HD
• Crop control on HDMI output
Video Processing
• Motion adaptive deinterlacer
• Proc amp controls
• Color corrector
•Legalizer
• Framerate conversion/film cadence removal/insertion (3:2, 1:2, 2:1, 2:3), except when
the input or output format is 4K/UltraHD)
• Adjustable delay of 0-6 frames with H and V timing controls in lines and pixels
• Closed Caption conversion (CEA-608/CEA-708)
• AFD input detection, down-convert control, and output pass through or overwrite
• Freeze (manual or on input signal loss) to black or last good frame
• Matte generator for background fill
• Video test generator
