FS4 Frame Synchronizer/Converter v1.1
• Frame Rate Conversion (3:2, 1:2, 2:1, but not for 4K/UHD converted to 4K/UHD)
• Quadrant and Two Sample Interleave (2SI) mapping conversion
• De-interlacing and Interlacing
•Video Proc Amp controls
• 3:2 cadence detection and removal for interlaced inputs and 3:2 cadence generation
on interlaced outputs
• Built in Test Pattern Generators
•Crop/Fill controls
• Matte generators for background fill
• Closed caption conversion (CEA-608/CEA-708)
• Adjustable output timing and delay
Audio Features • 48kHz, 24 bit audio (20 bit for SD)
• Balanced AES I/O (16 ch input, 16 ch output)
• MADI I/O (128 ch input, 128 ch output, via BNC and Fiber)
• Embedded Audio (4x16 ch I/O in Four Channel Mode)
• 277x208 routable mono audio matrix
• Audio Sample Rate Conversion available on all audio inputs
• Independent level, phase, delay controls for each audio channel
• 5.1 and 7.1 to Stereo mixdown processors
Other Features • Simple operation, redesigned menu structure and quick access to features via front
panel buttons or web UI
• Built in web server. Supports remote status and control and remote software updates
•Presets
• Redundant power
• Configurable Alarms
• EIA 19” Rack mountable 1RU frame, offering space, power and cost efficiencies ideal for
outdoor broadcast trucks, post production or broadcast settings
• Five-year international warranty with unlimited technical support.
FS4 Control
FS4 operation can be monitored and changed in a number of ways. Feature sets in each
of the control methods vary, although the front panel and web browser interfaces offer
many of the same features.
Front Panel Control The FS4 front panel offers the most direct control, ideal for use in machine rooms or
wherever quick changes and status checks must be made. The buttons and knobs
control menus in the display, allowing you to fully configure the system according to
your purposes. You can control inputs, outputs, processing paths, keying, and much
more.
