AJA FS4 - Proc Amp Black

www.aja.com
71
FS4 Frame Synchronizer/Converter v1.1
1.2 Proc Amp Black This parameter adjusts the video black level from -20 IRE to +20 IRE in 0.5 steps.
1.3 Proc Amp Hue This parameter adjusts the video color hue through 360 degrees (color wheel) in 1
degree steps.
1.4 Proc Amp Sat This parameter adjusts the video color saturation from black and white to 1.5 times
chroma in steps of 0.01.
2.0 Color Corrector
(RGB)
This parameter turns the RGB Color Corrector On and Off. When it is On, you can set
additional parameters to control RGB video Gain, Black Level, and Gamma. When set to
Off, all RGB Color Corrector settings are programmed for unity (or bypass).
Source Memory Independent RGB Color Correct parameter values are kept for each input format.
2.1 Color Red Gain This parameter adjusts the RGB Red Gain.
2.2 Color Red Black
Level
This parameter adjusts the RGB Red Black level.
2.3 Color Red Gamma This parameter adjusts the RGB Red Gamma.
2.4 -2.6 Color Green This set of parameters adjusts the Gain, Black Level, and Gamma for color Green, same as
Color Red described above.
2.7-2.9 Color Blue This set of parameters adjusts the Gain, Black Level, and Gamma for color Red Blue, same
as Color Red described above.
3.0 Video Legalizer These parameters allow adjustment of signal levels to meet legal broadcast
requirements. When set to Off, the Video Legalizer is not enabled, and the following clip
controls are not active. In YUV mode, the White Clip, Black Clip, and Chroma Clip controls
Variable Adjusts Proc Amp Black level from -20 IRE to +20 IRE in 0.5 steps.
Default (unity): 0 IRE
Variable Adjusts Proc Amp Hue from -179 to +180 in steps of 1 degree.
Default (unity): 0 degrees
Variable Adjusts Proc Amp Saturation from 0 (black & white) to 1.5
(Chroma) in steps of 0.01.
Default: 1.0
Off (default)
On
Sets the RGB Color Corrector to Off.
Sets the RGB Color Corrector to On, enabling the following Color
Corrector parameters.
Variable Adjusts Red Gain from zero to 1.5 in 0.01 steps.
Default (unity): 1.0
Variable Adjusts Red Black level from -20 IRE to +20 IRE in 0.5 steps.
Default (unity): 0 IRE
Variable Adjusts Red Gamma level from -1.0 to +1.0 in 0.01 steps.
Default (unity): 0
