FS4 Frame Synchronizer/Converter v1.1
See " Single Channel Mode Output Examples on page 41"
3.0 Link Config
SDI5-8
(Single CH only) These parameters determine how 1080p50/60, 6Gb, and 12Gb signals
are formatted for the Video Processor SFP output ports.
NOTE: 6Gb and 12Gb signal output requires compatible SFP modules.
See " Single Channel Mode Output Examples on page 41"
4 Output Image
Mapping
(Single Ch only) This parameter sets the structure of the UHD or 4K output video. The
image can be divided into four quadrants (Square Division [SQD] format, see SMPTE
425-3, Appendix B), or interleave (2 Sample Interleave [2SI] format (see SMPTE 425-5,
Section 8).
5 SD Aspect Ratio This parameter selects the type of SD-to-SD Aspect Ratio Conversion (ARC) performed on
an incoming selected SD source input. This parameter has an effect only when the input
and output are both SD (525i or 625i).
NOTE: Any Custom Size/Pos values (only available in Four Channel Mode) will be applied on top of
this settings.
QuadLnk Lvl A (default)
QuadLnk Lvl B
Sngl Lnk LvlA
Dual Link
Sngl Lnk LvlB
Sets the output transport to Quad Link Level A (four
connectors).
Sets the output transport to Quad Link Level B-DL (four
connectors).
Sets the output transport to 3Gb, 6Gb, or 12Gb Level A (single
connector).
Sets the output transport to 1.5Gb or 3Gb Dual Link (two
connectors)
Sets the output transport to 3Gb Level B-DL (single connector).
Quadrant (default)
Interleave
The output is Quadrant format (Square Division).
The output is Two Sample Interleave format. The front panel 2SI
LED will light when selected.
Off (default)
Letterbox
H Crop
Pillarbox
V Crop
14x9
No ARC conversion will be performed.
Selects the indicated ARC conversion.
