FS4 Frame Synchronizer/Converter v1.1
NOTE: Unlike most knob-adjustable parameters, on the front panel menu this parameter
automatically wraps around from the maximum value to 0 (and vice versa).
1 Output Timing H When adjusting the horizontal timing (H), this parameter specifies a number of pixels to
offset, from zero to full line width. Adjustment range increments from 0 to the width of
the line in pixels. The maximum value varies, depending on the format already chosen.
2 Output Timing V When adjusting the vertical timing (V), this parameter specifies a number of lines to
offset, moving the screen up to a half a frame up or down.
Output Timing Memory Independent horizontal and vertical timing values are kept for all available output
formats.
Output Timing Ranges The table below lists the output timing ranges for various video frame rates.
Variable Adjustment range increments from 0 to the width of the line in
pixels. The maximum varies, depending on the format chosen.
Default: 0
Variable Adjustment range increments from half a frame up to a half a
frame down in single line increments. The maximum varies,
depending on the format already chosen.
Default: 0
Table 10. Output Timing Ranges
Output Frame Rate
Horizontal Vertical
Min Max Min Max
UHD23.98 0 2749 -562 562
UHD24 0 2749 -562 562
UHD25 0 2639 -562 562
UHD29.97 0 2199 -562 562
UHD50 0 2639 -562 562
UHD59.94 0 2199 -562 562
4K1080p23.98 0 2749 -562 562
4K1080p24 0 2749 -562 562
4K1080p25 0 2639 -562 562
4K1080p29.97 0 2199 -562 562
4K1080p50 0 2639 -562 562
4K1080p59.94 0 2199 -562 562
1080i50 0 2639 -562 562
1080i59.94, 1080i60 0 2199 -562 562
1080p23.98, 1080p24 0 2749 -562 562
1080p25 0 2639 -562 562
1080p29.97, 1080p30 0 2199 -562 562
1080p50 0 2639 -562 562
1080p59.94, 1080p60 0 2199 -562 562
1080psf23.98, 1080psf24 0 2749 -562 562
1080psf25 0 2639 -562 562
1080psf29.97, 1080psf30 0 2199 -562 562
