FS4 Frame Synchronizer/Converter v1.1
NOTE: The STATUS menu always shows the FS4’s current Ethernet settings. The parameters shown on
the CONFIG Menu Group IP configuration menu may not display the values the unit is
currently using.
Vid 1/2 I/O (4Ch only) This menu shows the current primary video settings for Video Processors 1
and 2.
Vid 3/4 I/O (4Ch only) Same as Vid 1/2 I/O status menu, except for Video Processors 3 and 4.
Vid I/O (SingleCh only) This menu shows the current primary video settings for Video Processor.
Vid 1 Format (4Ch only) This menu shows the current primary video settings for Video Processor 1.
Vid 2-4 Format (4Ch only) Same as Vid 1 Format menu, except for Video Processors 2-4.
Vid 1 Alarm (4Ch only) This menu shows the Video Processor 1 alarm status. Absence of alarm shows
as OK. If selections are incompatible, the status of the affected signal shows Incompat.
Vid 2-4 Alarm (4Ch only) Same as Vid 1 Alarm menu, except for Video Processors 2-4.
Display Description
IN1 Input Source Format
OUT1 Output Source Format
IN2 Input Source Format
OUT2 Output Source Format
Selected (physical) video 1 input & detected format.
Selected video output 1 format & selected audio input used
on output.
Selected (physical) video 2 input & detected format.
Selected video output 2 format & selected audio input used
on output.
Display Description
IN Input Source(s) Format
GEN Genlock Source Status
OUT Format AudIn
Vid CC Status
Selected (physical) video 1-4 inputs & detected format.
Selected Genlock source and format.
Selected video output format & selected audio input used
on output
Closed Caption status (
Display Description
IN1 Input Source Format
BKGD Backgd Source
GEN Genlock Source Format
OUT1 Format
Selected video input source and format.
Selected Background video source.
Selected Genlock source and format.
Selected video output format.
Display Description
IN1 Input Source Status
BKGD Backgd Source Status
GEN Genlock Source Status
Rate Status
Video input source alarm status.
Selected Background video source alarm status.
Selected Genlock source alarm status.
System Output Frame Rate (59/29/23.98, 50/25, 60/30/24)
