AJA FS4 - SDI 1 Delay Global

www.aja.com
86
FS4 Frame Synchronizer/Converter v1.1
1.1 SDI 1 Delay Global When Global is selected above, the individual SDI 1 audio channel pair menus are
hidden.
1.1-1.8 SDI 1 Channel
Pair Delay
When Channel Pair is selected above, eight individual SDI 1 audio channel pair menus
become available, permitting adjusting the delay of each input channel pair.
• Delay adjustment range is -128 to +12288 in units of samples where 48 samples = 1
millisecond. The Front Panel displays the delay in milliseconds and as fractions of
milliseconds in units of samples.
2.0 - 8.0 SDI2-8 Delay Same as 1.0 SDI1 Delay menu, except for SDI inputs 2 through 8, and similar delay adjust
submenus are available.
AES/MADI Delay
Menus
When AES is selected, Delay parameter menus for AES and MADI input audio are
displayed. These menus are the similar to those used for Embedded Audio SDI1 Delay.
1.0 AES Delay Sixteen AES Level menus (and related submenus) are available.
2.0 MADI BNC Delay Sixty four MADI BNC Level (and related submenus) are available.
3.0 MADIFIB Delay Sixty four MADI Fiber Level (and related submenus) are available.
NOTE: For level adjustment information, see “1.0 SDI1 Delay” on page 85.
MAP Menu Group
IMPORTANT: The settings in this menu group apply to the currently selected audio category (EMBED
or AES/MADI). These settings are NOT shared with both Four Channel and Single Channel
modes.
The MAP menus provide FS4 audio routing controls. Any audio input can be routed to
any audio output, except the Monitor output embedded audio always matches the
monitored video.
About Audio
Routing
The following menus control the FS4’s audio routing. The general routing procedure
using the front panel is to select the menu of the audio output with the SELECT knob, and
then select the input source you wish to route to that output with the ADJUST knob.
Channel mapping allows different individual audio channels to be routed to different
individual outputs.
See “System Video/Audio Cable Connections” on page 33 for more information about FS4
signal routing.
SDI 1 Delay Global The ADJUST knob sets the Global delay value. Adjustment range is
-128 to +12288 in units of samples where 48 samples = 1
millisecond.
The Front Panel displays the delay in milliseconds and as fractions of
milliseconds in units of samples.
