Alarm Configuration Screen
You can pop open the Alarm Configuration display at any time and on any screen by
clicking the gear button in the upper part of the Alarms panel.
To close the window, press the ESC key, or click the X in the upper right corner.
The Alarm Configuration display provides control over these alarm settings:
• Power Supply Alarm (see “5.1, 5.2 Power Supply 1-2 Alarm” on page 58)
• Video Format Alarm (see “6 Vid Format Alarm” on page 58)
• Reference Alarm (see “7 Reference Alarm” on page 58)
Alarm
Configuration
popup display
FS4 Alarms
display button
(gear icon)
