FS4 Frame Synchronizer/Converter v1.1
Name Entry Procedure Set the name as follows:
1. Push ADJUST momentarily to enter character editing mode.
2. Turn SELECT to advance the blinking cursor to each character.
3. Turn ADJUST to scroll through the choices for each character. These characters are
allowed: A through Z (uppercase), a through z (lowercase), numerals, hyphen (-),
period (.), and space (blank). Leave the desired character selected and advance to the
next one.
4. Push ADJUST to save and activate the name after all characters are defined.
• To abandon changes before saving, push SELECT.
• To return to the default name at any time, hold down ADJUST.
NOTE: To eliminate trailing characters to shorten an existing system name, overwrite them with a
hyphen (-) or space.
2 FS4 Mode Selects whether the FS4 will operate in Four Channel or Single Channel mode. Pressing
the ADJUST knob at the “Change Mode?” prompt will reboot the FS4 in the other
operating mode. During reboot, the display shows [Rebooting], goes dark momentarily,
and then shows the percentage of progress as the system reboots. Reboot should take
no longer than 90 seconds. This parameter has no default setting (is only be used to
change to the other mode) and is not saved in Presets.
3.1 IP Config This parameter determines the type of TCP/IP network configuration used by the FS4.
Consult your network administrator about how to set this value.
3.2 IP Address This parameter determines the static IP address used by the FS4 for TCP/IP networking.
Consult your network administrator about how to set this value.
Octet Value Entry
Procedure
Set the octets (numbers between periods) values as follows:
1. Push ADJUST momentarily to enter edit mode.
2. Turn SELECT to select the octet you want to edit, indicated by blinking.
3. Turn ADJUST to enter the new value.
• If you need to revert to the previous setting (undo changes), push SELECT.
4. Push ADJUST momentarily to save and activate the new setting.
• If you want to revert to the default value, hold down ADJUST for 4 seconds.
HD/SD
4K/UHD
After reboot the FS4 will operate in Four Channel (HD/SD) mode.
After reboot the FS4 will operate in Single Channel (4K/UHD) mode.
DHCP (default)
Static Addr
Select automatic IP address assignment from the LAN DHCP server. If
the FS4 cannot find a DHCP server, it fails over to the static IP address.
Assign a static IP address manually (using the following parameter
menus). The FS4 factory default static IP address is 192.168.0.2.
IP Address variable If IP Config is set to DHCP dynamic addressing (default), the IP Address is
set automatically by the network's DHCP server.
If IP Config is set to Static Addr, manually enter an IP address.
If IP Config is set to DHCP and there is a DHCP failure, the IP address is set
to the static IP address. The factory default static IP address is
192.168.0.2.
