AJA FS4 - REMOTE Menu Group

www.aja.com
50
FS4 Frame Synchronizer/Converter v1.1
Caption Status (4Ch only) This menu shows what type of closed caption data is selected and whether
closed caption data is present on the selected video input.
REMOTE Menu Group
The REMOTE Menu Group lets you set up how you want the FS4 to be controlled. Control
options include the front panel, a remote computer running a browser, and GPI inputs
and outputs.
NOTE: The Remote Menu Group parameters available on the front panel interact with the browser
parameters available on an attached computer, and vice versa. For example, once the
Remote Control parameter is set to 'Local Only' from either the browser or front panel, all
future settings will only be able to be changed from the front panel. The opposite is true if set
to 'Remote Only'. However the Remote Control parameter is always available from the front
panel, regardless of how it is set.
1 Remote Control This parameter determines whether the FS4 panel responds to controls locally from the
front panel, from a network attached computer with a web browser, or both. The
selected mode is indicated by the color of the REMOTE LED.
1.1 Authentication This parameter enables or disables an authentication login requirement. By default this
parameter is set to Disabled.
When you select Login via the front panel parameter, you must then go to the browser
interface to perform a login each time you access the FS4. The browser presents the login
screen first, requiring you to log in before you can access any other browser screens. The
password is initially set to the default value, but you can change it using the Remote
browser screen.
The default password is password.
NOTE: If authentication is used, it provides only a minimum security safeguard against
unauthorized use of the FS4. The authentication mechanism is simple and does not provide
robust security.
Display Description
Vid1 CC Caption Type & Presence
Vid2 CC Caption Type & Presence
Vid3 CC Caption Type & Presence
Vid4 CC Caption Type & Presence
For Video Processors 1-4, selected caption type
(SD/HD/Invalid), and presence (Detected/Not
detected/Pass Thru).
Local + Remote (default)
Local Only
Remote Only
Control from the front panel, a remote control panel, or a network-
attached browser. The REMOTE LED lights purple.
Control only from the front panel (browsers cannot change
parameters). The REMOTE LED lights blue.
Control only from a network attached browser or remote control
panel. The REMOTE LED lights red.
Disabled (default)
Login
Disables the requirement for a login password. No password is
needed.
Login is required via the web browser interface before changes
can be made. After selecting Login, depending on the browser a
new browser window may be necessary (i.e. just a page refresh
or reload may not get rid of the login page).
