FS4 Frame Synchronizer/Converter v1.1
• 128-Channels, 24-bit (20-bit SD), SMPTE-272/299
• 8 x balanced AES inputs (16-Channels), 1 x DB-25
• 16-Channels, 24-bit, AES-3
• 2 x MADI inputs, 1 BNC, 1 x ST Fiber
• 56 or 64 channels, 24bit, AES10 per input
Audio Output Digital
•48 kHz sample rate
• 1 x SDI embedded output per Video Processor (16-Channels each)
• 16-Channels (in single Video Processor mode), 24-bit (20-bit SD), SMPTE-272/299
• 64-Channels (in four Video Processor mode), 24-bit (20-bit SD), SMPTE-272/299
• 8 x balanced AES outputs (16-Channels), 1 x DB-25
• 16-Channels, 24-bit, AES-3
• 2 x MADI outputs, 1 BNC, 1 x ST Fiber
• 128-Channels, 24-bit, AES-10
Audio Processing
• 277 x 208 mono audio matrix, route 1 to 1, 1 to many
• Inputs: 128 embedded, 16 AES, 128 MADI, 2 stereo mixdowns, 3 tone generator
• Outputs (Four Ch Mode): 16 AES, 128 MADI, 64 embedded
• Outputs (Single Ch Mode): 16 AES, 128 MADI, 16 embedded
• Input adjustment controls for each channel
• Gain +18 to -18 dB in 0.5 dB steps
• Phase invert
• Input adjustment controls for each channel pair
• Delay -16ms to +1sec in 20.8 us steps
• Two independent 5.1 or 7.1 to stereo mixdown processors with gain adjust
• High quality Sample Rate Conversion supported on all audio inputs
• SRC bypass for non-PCM audio (e.g. Dolby E, AC-3, etc)
• Audio tone generator (mute, 400 Hz, 1 kHz)
Reference Input
• External, 2 x BNC
• Looping, nonterminating
• Blackburst or tri-level sync
• External termination required
