FS4 Frame Synchronizer/Converter v1.1
• The REF LED will light red, indicating an alarm condition. By default the FS4 is
configured to operate genlocked to an external reference signal.
2. Press the front panel STATUS button, then turn the SELECT knob to view various
Status menus.
• The Status menu for Video Processor 1 will report No Input for IN1, the port is
disconnected), and the GEN (Genlock) parameter will report Ref (configured for
external reference) but will also report No Input.
3. Connect a 1080i59.94 HD tri-level sync reference signal to one of the FS4 Ref Loop
BNCs, and connect a 75 ohm terminator to the other Ref BNC.
• The REF LED will light blue, indicating the FS4 is genlocked to reference.
•The Status menu GEN parameters will report Ref and indicate the format of the
incoming reference signal or OK.
• However, because the FS4 is still not receiving a compatible video input, No Input,
will be reported for IN1.
4. Connect a 1080i59.94 SDI video source to the SDI 1 input BNC.
• The front panel will report 1080i59 and an OK status for SDI 1.
This indicates no alarm condition exists.
5. Disconnect one of the power cords, leaving the other attached.
• The front panel PWR LED will light red for the power supply with the removed
cord.
• The PS status will report PS1 (or 2) OFF
6. Reconnect the power cable. The PWR LED for that power supply will light blue and
the power supply status will report OK.
This workflow confirms the FS4 powers up successfully and reports reference and power
supply alarms.
NOTE: FS4 Reference, Power Supply, and Video Format alarms can be disabled, if desired. This will
prevent the LEDs from going red, but will not affect SNMP or front panel status displays.
Video Format Status screen Video Format Alarm Status screen
IN1 SDI 1 No Input
BKGD Black 1080i59
GEN Ref No Input
OUT1 1080i59
IN1 SDI 1 OK
BKGD Black OK
GEN Ref No Ref
Rate 59/29/23
Video Format Status screen Video Format Alarm Status screen
IN1 SDI 1 No Input
BKGD Black 1080i59
GEN Ref 1080i59
OUT1 1080i59
IN1 SDI 1 OK
BKGD Black OK
GEN Ref OK
Rate 59/29/23
Video Format Status screen Video Format Alarm Status screen
IN1 SDI 1 1080i59
BKGD Black 1080i59
GEN Ref 1080i59
OUT1 1080i59
IN1 SDI 1 OK
BKGD Black OK
GEN Ref OK
OUT1 1080i59
