Akai MPC Touch User Manual

189
The Pad Mixer works like an audio mixer with various settings for each pad, shown in a 4x4 array. All of
their functionality is identical. If a sample has been assigned to a pad, its name is displayed at the top of it.
To select a pad, press its corresponding pad or tap it on the touchscreen. Alternatively, use the Pad
field in the upper-left corner.
To view more channels, use the Pad Bank Buttons.
Use the Program field in the upper-left corner to select the program whose pads you want to view.
Remember that only drum programs or keygroup programs will display properly in the Pad Mixer.
Use the Track field at the top of the touchscreen to select the desired track.
The counter indicates the current playhead position.
To adjust the position, tap it, and then use the use the Data Dial or the –/+
buttons.
To switch the time increments, double-tap it. You can view it in Bars, Beats,
and Ticks or in hours (HH), minutes (MM), seconds (SS), and frames (FF).
To view a specific setting on all channels, tap the Level, Pan, Mute, Send, Insert, or Route button
on the bottom edge of the touchscreen. You can tap the Send or Insert buttons multiple times to cycle
through the four available slots for each.

Akai MPC Touch Specifications

General

Display type	LED
Built-in display	Yes
Product color	Black
USB direct playback	-
Built-in optical drive	No
Audio (L/R) in	2
Minimum RAM	4 GB
Minimum processor	Dual Core
Minimum processor speed	2.5 GHz
Minimum storage drive space	2048 MB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8
