Akai MPC Touch User Manual

244
The following controls and tabs are available for all of the mixers (or most of them, as indicated):
To select a channel, press its corresponding pad or tap it on the touchscreen. Alternatively, use the
field in the upper-left corner.
To view more channels (while viewing tracks of programs), use the –/+ buttons at the top of the
touchscreen or the Pad Bank Buttons.
The counter indicates the current playhead position.
To adjust the position, tap it, and then use the use the Data Dial or the –/+ buttons.
To switch the time increments, double-tap it. You can view it in Bars, Beats, and
Ticks or in hours (HH), minutes (MM), seconds (SS), and frames (FF).
Levels
When the Level tab is selected, use the Data Dial or –/+ buttons to adjust the level of the currently
selected track, program, return, submix, or master.
The level sliders and meters in each pad show a visual representation of the level. Double-tap a pad in
the touchscreen to open a large version of the level slider and meter.
Panning
When the Pan tab is selected, use the Data Dial or –/+ buttons to adjust the panning of the currently
selected track, program, return, submix, or master.
The pan sliders in each pad show a visual representation of the level. Double-tap a pad in the
touchscreen to open a large version of the pan knob.

Akai MPC Touch Specifications

General

Display type	LED
Built-in display	Yes
Product color	Black
USB direct playback	-
Built-in optical drive	No
Audio (L/R) in	2
Minimum RAM	4 GB
Minimum processor	Dual Core
Minimum processor speed	2.5 GHz
Minimum storage drive space	2048 MB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8
