79
To load a keygroup insert effect in the Pad Mixer:
1. Use the Program field at the top of the touchscreen to select the desired program. Alternatively, use
the Track field at the top of the touchscreen to select the desired track—the program it uses will be
selected automatically.
2. Press a pad to select its corresponding keygroup, or tap it in the touchscreen. Alternatively, double-
tap the Keygroup field below the Program field.
Important: Remember that regardless of the keygroup, the effect will be applied to the entire
keygroup program. You can still load up to four insert effects per keygroup, but all of them will affect
the entire program.
3. Tap the pencil icon next to Inserts, and then use the window that appears to load or edit effects.
Alternatively, double-tap the desired pad in the touchscreen. You could also select one of the four
Insert tabs at the bottom of the touchscreen, and then use the Data Dial or –/+ buttons to select an
effect immediately.
To load a keygroup insert effect in Program Edit Mode:
1. In the software window, click the Program Edit tab at the top of the screen. Alternatively, press
Ctrl+2 (Windows) or
+2 (Mac OS X) on your computer keyboard.
2. In the Keygroup section in the lower-left corner of the window, use the KG Select menu to select the
desired keygroup.
Important: Remember that regardless of the keygroup, the effect will be applied to the entire
keygroup program. You can still load up to four insert effects per keygroup, but all of them will affect
the entire program.
3. If the button above the Keygroup Inserts slots is set to Off, click it
so it changes to On.
4. Click the downward arrow (T) of one of the insert slots, and then
use the window that appears to load effects.
To edit an effect’s parameters, double-click its name in the insert
slot, and then use the window that appears to edit it.
To Next Page
