Akai MPC Touch User Manual

83
To load a master insert effect in the Channel Mixer:
1. Set the Mixer field in the upper-left corner to Masters.
2. In the touchscreen, tap the pad that corresponds to the desired master output (Outputs 1/2,
Outputs 3/4, etc.). Alternatively, double-tap the Outputs field below the Mixer field.
3. Tap the pencil icon next to Inserts, and then use the window that appears to load or edit effects.
Alternatively, tap the Insert tab at the bottom of the touchscreen (tap it multiple times to select a
different insert slot), and then double-tap the desired pad in the touchscreen. You could also use the
Data Dial or –/+ buttons to select an effect immediately.

Akai MPC Touch Specifications

General

Display type	LED
Built-in display	Yes
Product color	Black
USB direct playback	-
Built-in optical drive	No
Audio (L/R) in	2
Minimum RAM	4 GB
Minimum processor	Dual Core
Minimum processor speed	2.5 GHz
Minimum storage drive space	2048 MB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8
