Akai MPC Touch User Manual

82
Submixes
You can load up to 4 insert effects to each submix. You can do this in the Channel Mixer only.
To load a submix insert effect:
1. Set the Mixer field in the upper-left corner to Submixes.
2. In the touchscreen, tap the pad that corresponds to the desired program. Alternatively, double-tap
the Submix field below the Mixer field.
3. Tap the pencil icon next to Inserts, and then use the window that appears to load or edit effects.
Alternatively, tap the Insert tab at the bottom of the touchscreen (tap it multiple times to select a
different insert slot), and then double-tap the desired pad in the touchscreen. You could also use the
Data Dial or –/+ buttons to select an effect immediately.
Masters
You can load up to 4 insert effects to each master output (a stereo pair of channels: Outputs 1/2,
Outputs 3/4, etc.). You can do this in Main Mode or the Channel Mixer.
To load a master insert effect in Main Mode:
1. If the channel strip is not already shown, tap the small triangle (X) icon below the Project field to
show it.
2. Tap the fourth (crown) icon at the top of the channel strip. The channel strip will now show settings
for the current master output.
3. Use the Outputs field at the top of the channel strip to select the desired master output (Outputs
1/2, Outputs 3/4, etc.).
4. Tap the pencil icon next to Inserts, and then use the window that appears to load or edit effects.

Akai MPC Touch Specifications

General

Display type	LED
Built-in display	Yes
Product color	Black
USB direct playback	-
Built-in optical drive	No
Audio (L/R) in	2
Minimum RAM	4 GB
Minimum processor	Dual Core
Minimum processor speed	2.5 GHz
Minimum storage drive space	2048 MB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8
