81
To load an insert effect in Program Edit Mode:
1. In the software window, click the Program Edit tab at the top of the
screen. Alternatively, press Ctrl+2 (Windows) or
+2 (Mac OS X) on
your computer keyboard.
2. If the button above the Program Inserts slots is set to Off, click it so
it changes to On.
3. Click the downward arrow (T) of one of the insert slots, and then use
the window that appears to load effects.
To edit an effect’s parameters, double-click its name in the insert slot,
and then use the window that appears to edit it.
Important:
For drum programs, if the Pad Audio Route menu is set to anything other than Program, then the
effect will not be applied to that pad.
For keygroup programs, if the Keygroup Audio Route menu is set to anything other than Program,
then the effect will not be applied to that entire keygroup program.
To load a program insert effect in the Channel Mixer:
1. Set the Mixer field in the upper-left corner to Programs.
2. In the touchscreen, tap the pad that corresponds to the desired program. Alternatively, double-tap
the Program field below the Mixer field.
3. Tap the pencil icon next to Inserts, and then use the window that appears to load or edit effects.
Alternatively, tap the Insert tab at the bottom of the touchscreen (tap it multiple times to select a
different insert slot), and then double-tap the desired pad in the touchscreen. You could also use the
Data Dial or –/+ buttons to select an effect immediately.
