Akai MPC Touch User Manual

85
Pads
You can set the send levels for pads in Program Edit Mode or the Pad Mixer.
To set the send levels for a pad in Program Edit Mode:
1. While editing the desired program in Program Edit Mode, press the desired pad to select it.
2. Tap the Effects tab in the lower-right corner.
3. Use the Send knobs to set the send level for each return.
To set the send levels for a pad in the Pad Mixer:
1. Use the Program field at the top of the touchscreen to select the desired program. Alternatively, use
the Track field at the top of the touchscreen to select the desired track—the program it uses will be
selected automatically.
2. Tap the Send tab at the bottom of the touchscreen (tap it multiple times to select a different send
level).
3. Press the desired pad to select it, or tap it in the touchscreen. Alternatively, double-tap the Pad field
below the Program field.
4. Use the Data Dial or –/+ buttons to set the send level. To make finer adjustments, double-tap the
pad and adjust the larger version of the slider that appears.
