Keygroups
You can set the send levels for keygroups in Program Edit Mode or the Pad Mixer.
To set the send levels for a keygroup in Program Edit Mode:
1. In the software window, click the Program Edit tab at the top of the screen.
Alternatively, press Ctrl+2 (Windows) or
a
+2 (Mac OS X) on your computer keyboard.
2. If the Send button above the desired keygroup’s channel strip is not already selected,
click it.
3. Click and drag the knob that corresponds to each return up or down.
To set the send levels for a keygroup in the Pad Mixer:
1. Use the Program field at the top of the touchscreen to select the desired program. Alternatively, use
the Track field at the top of the touchscreen to select the desired track—the program it uses will be
selected automatically.
2. Tap the Send tab at the bottom of the touchscreen (tap it multiple times to select a different send
level).
3. Press the desired pad to select its corresponding keygroup, or tap it in the touchscreen.
Alternatively, double-tap the Keygroup field below the Program field.
4. Use the Data Dial or –/+ buttons to set the send level. To make finer adjustments, double-tap the
pad and adjust the larger version of the slider that appears.

Akai MPC Touch Specifications

General

Display type	LED
Built-in display	Yes
Product color	Black
USB direct playback	-
Built-in optical drive	No
Audio (L/R) in	2
Minimum RAM	4 GB
Minimum processor	Dual Core
Minimum processor speed	2.5 GHz
Minimum storage drive space	2048 MB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8
