134 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Chapter 4 Bulletin 290E/291E/294E Programmable Parameters
MotorOLCurrent
Set to the maximum allowable motor current.
Parameter Number 30
Related Parameter 31, 80, 82…83
Access Rule GET/SET
Data Type UINT
Group Motor and Control
Cat. No. Hp (kW) Min Amps Default Amps Units x.x Amps
294_FD1P5 0.5 (0.4) 0 1.5 Minimum Value 0
294_FD2P5 1.0 (0.75) 0 2.5 Maximum Value Cat. No. Dependent
294_FD4P2 2.0 (1.5) 0 3.6 Default Value Cat. No. Max Output
CurrentLimit
Maximum output current allowed before current limiting occurs
Parameter Number 31
Related Parameters
Access Rule GET/SET
Data Type UINT
Group Motor and Control
Cat. No. Hp (kW) Units x.x Amps
294_FD1P5 0.5 Hp Min = 0; Max = 2.7; Default = 2.2 Minimum Value 0
294_FD2P5 1.0 Hp Min = 0; Max = 4.5; Default = 3.7 Maximum Value Cat. No. Dependent
294_FD4P2 2.0 Hp Min = 0; Max = 7.5; Default = 6.3 Default Value Cat. No. Dependent
StopMode
Valid Stop Mode for the Bulletin 294E ArmorStart LT are the following:
0 = RampToStop, “Stop” command clears active fault
1 = Coast to Stop, “Stop” command clears active fault
2 = DCBrake, DC Injection Braking Stop, “Stop” command clears active fault
3 = DCBrakeAuto, DC Injection Stop with Auto Shutoff
Standard DC Injection Braking for value set in Parameter 75 (DC Brake Time)
or
Drive shuts off if current limit is exceeded.
Parameter Number 32
Related Parameters
Access Rule GET/SET
Data Type UINT
Group Motor and Control
Units —
Minimum Value 0
Maximum Value 3
Default Value 0
