86 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Chapter 3 Product Commissioning
Table 10 - Default Consume Assembly for Bulletin 294E
Table 11 - Bulletin 294E Consume Assembly Command Tags
Instance 154 “Drive Cmd” – Default Consumed Assembly for Bulletin 294 Starters
ByteBit 7Bit 6Bit 5Bit 4Bit 3Bit 2Bit 1Bit 0
0 JogReverse JogForward ResetFault RunReverse RunForward
1 Decel2 Accel2 Out05 Out04 Out03 Out02 Out01 Out00
2 CommandFreq (Low) (xxx.x Hz)
3 CommandFreq (High) (xxx.x Hz)
4 Pt07DeviceIn Pt06DeviceIn Pt05DeviceIn Pt04DeviceIn Pt03DeviceIn Pt02DeviceIn Pt01DeviceIn Pt00DeviceIn
5 Pt15DeviceIn Pt14DeviceIn Pt13DeviceIn Pt12DeviceIn Pt11DeviceIn Pt10DeviceIn Pt09DeviceIn Pt08DeviceIn
6 AnalogDeviceIn (low byte)
7 AnalogDeviceIn (high byte)
Device Name Name Logix Tag Name Data Type Style
ASLT_DEMO RunForward ASLT_DEMO:O.RunForward BOOL Decimal
ASLT_DEMO RunReverse ASLT_DEMO:O.RunReverse BOOL Decimal
ASLT_DEMO ResetFault ASLT_DEMO:O.ResetFault BOOL Decimal
ASLT_DEMO JogForward ASLT_DEMO:O.JogForward BOOL Decimal
ASLT_DEMO JogReverse ASLT_DEMO:O.JogReverse BOOL Decimal
ASLT_DEMO Pt00Data ASLT_DEMO:O.Pt00Data BOOL Decimal
ASLT_DEMO Pt01Data ASLT_DEMO:O.Pt01Data BOOL Decimal
ASLT_DEMO Pt02Data ASLT_DEMO:O.Pt02Data BOOL Decimal
ASLT_DEMO Pt03Data ASLT_DEMO:O.Pt03Data BOOL Decimal
ASLT_DEMO Pt04Data ASLT_DEMO:O.Pt04Data BOOL Decimal
ASLT_DEMO Pt05Data ASLT_DEMO:O.Pt05Data BOOL Decimal
ASLT_DEMO Accel2 ASLT_DEMO:O.Accel2 BOOL Decimal
ASLT_DEMO Decel2 ASLT_DEMO:O.Decel2 BOOL Decimal
ASLT_DEMO FreqCommand ASLT_DEMO:O.FreqCommand INT Decimal
ASLT_DEMO Pt00DeviceIn ASLT_DEMO:O.Pt00DeviceIn BOOL Decimal
ASLT_DEMO Pt01DeviceIn ASLT_DEMO:O.Pt01DeviceIn BOOL Decimal
ASLT_DEMO Pt02DeviceIn ASLT_DEMO:O.Pt02DeviceIn BOOL Decimal
ASLT_DEMO Pt03DeviceIn ASLT_DEMO:O.Pt03DeviceIn BOOL Decimal
ASLT_DEMO Pt04DeviceIn ASLT_DEMO:O.Pt04DeviceIn BOOL Decimal
ASLT_DEMO Pt05DeviceIn ASLT_DEMO:O.Pt05DeviceIn BOOL Decimal
ASLT_DEMO Pt06DeviceIn ASLT_DEMO:O.Pt06DeviceIn BOOL Decimal
ASLT_DEMO Pt07DeviceIn ASLT_DEMO:O.Pt07DeviceIn BOOL Decimal
ASLT_DEMO Pt08DeviceIn ASLT_DEMO:O.Pt08DeviceIn BOOL Decimal
ASLT_DEMO Pt09DeviceIn ASLT_DEMO:O.Pt09DeviceIn BOOL Decimal
ASLT_DEMO Pt10DeviceIn ASLT_DEMO:O.Pt10DeviceIn BOOL Decimal
ASLT_DEMO Pt11DeviceIn ASLT_DEMO:O.Pt11DeviceIn BOOL Decimal
ASLT_DEMO Pt12DeviceIn ASLT_DEMO:O.Pt12DeviceIn BOOL Decimal
ASLT_DEMO Pt13DeviceIn ASLT_DEMO:O.Pt13DeviceIn BOOL Decimal
