88 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Chapter 3 Product Commissioning
Table 13 - Bulletin 294E Produced Assembly Status Tags
Device Name Name Logix Tag Name Data Type Style
ASLT_DEMO Fault ASLT_DEMO:I.Fault DINT Binary
ASLT_DEMO TripPresent ASLT_DEMO:I.TripPresent BOOL Decimal
ASLT_DEMO WarningPresent ASLT_DEMO:I.WarningPresent BOOL Decimal
ASLT_DEMO RunningForward ASLT_DEMO:I.RunningForward BOOL Decimal
ASLT_DEMO RunningReverse ASLT_DEMO:I.RunningReverse BOOL Decimal
ASLT_DEMO Ready ASLT_DEMO:I.Ready BOOL Decimal
ASLT_DEMO NetworkControlStatus ASLT_DEMO:I.NetworkControlStatus BOOL Decimal
ASLT_DEMO NetworkReferenceStatus ASLT_DEMO:I.NetworkReferenceStatus BOOL Decimal
ASLT_DEMO AtReference ASLT_DEMO:I.AtReference BOOL Decimal
ASLT_DEMO DeviceLogixEnabled ASLT_DEMO:I.DeviceLogixEnabled BOOL Decimal
ASLT_DEMO KeypadAuto ASLT_DEMO:I.KeypadAuto BOOL Decimal
ASLT_DEMO KeypadOff ASLT_DEMO:I.KeypadOff BOOL Decimal
ASLT_DEMO KeypadHand ASLT_DEMO:I.KeypadHand BOOL Decimal
ASLT_DEMO KeypadJogging ASLT_DEMO:I.KeypadJogging BOOL Decimal
ASLT_DEMO DisconnectClosed ASLT_DEMO:I.DisconnectClosed BOOL Decimal
ASLT_DEMO BrakeContactorStatus ASLT_DEMO:I.BrakeContactorStatus BOOL Decimal
ASLT_DEMO OutputFrequency ASLT_DEMO:I.OutputFrequency INT Decimal
ASLT_DEMO Pt00Data ASLT_DEMO:I.Pt00Data BOOL Decimal
ASLT_DEMO Pt01Data ASLT_DEMO:I.Pt01Data BOOL Decimal
ASLT_DEMO Pt02Data ASLT_DEMO:I.Pt02Data BOOL Decimal
ASLT_DEMO Pt03Data ASLT_DEMO:I.Pt03Data BOOL Decimal
ASLT_DEMO Pt04Data ASLT_DEMO:I.Pt04Data BOOL Decimal
ASLT_DEMO Pt05Data ASLT_DEMO:I.Pt05Data BOOL Decimal
ASLT_DEMO Pt00DeviceOut ASLT_DEMO:I.Pt00DeviceOut BOOL Decimal
ASLT_DEMO Pt01DeviceOut ASLT_DEMO:I.Pt01DeviceOut BOOL Decimal
ASLT_DEMO Pt02DeviceOut ASLT_DEMO:I.Pt02DeviceOut BOOL Decimal
ASLT_DEMO Pt03DeviceOut ASLT_DEMO:I.Pt03DeviceOut BOOL Decimal
ASLT_DEMO Pt04DeviceOut ASLT_DEMO:I.Pt04DeviceOut BOOL Decimal
ASLT_DEMO Pt05DeviceOut ASLT_DEMO:I.Pt05DeviceOut BOOL Decimal
ASLT_DEMO Pt06DeviceOut ASLT_DEMO:I.Pt06DeviceOut BOOL Decimal
ASLT_DEMO Pt07DeviceOut ASLT_DEMO:I.Pt07DeviceOut BOOL Decimal
ASLT_DEMO Pt08DeviceOut ASLT_DEMO:I.Pt08DeviceOut BOOL Decimal
ASLT_DEMO Pt09DeviceOut ASLT_DEMO:I.Pt09DeviceOut BOOL Decimal
ASLT_DEMO Pt10DeviceOut ASLT_DEMO:I.Pt10DeviceOut BOOL Decimal
ASLT_DEMO Pt11DeviceOut ASLT_DEMO:I.Pt11DeviceOut BOOL Decimal
ASLT_DEMO Pt12DeviceOut ASLT_DEMO:I.Pt12DeviceOut BOOL Decimal
ASLT_DEMO Pt13DeviceOut ASLT_DEMO:I.Pt13DeviceOut BOOL Decimal
ASLT_DEMO Pt14DeviceOut ASLT_DEMO:I.Pt14DeviceOut BOOL Decimal
ASLT_DEMO Pt15DeviceOut ASLT_DEMO:I.Pt15DeviceOut BOOL Decimal
ASLT_DEMO Int00DeviceOut ASLT_DEMO:I.Int00DeviceOut INT Decimal
ASLT_DEMO OutputCurrent ASLT_DEMO:I.OutputCurrent INT Decimal
ASLT_DEMO OutputVoltage ASLT_DEMO:I.OutputVoltage INT Decimal
