Allen-Bradley Compact 5000 Series - Thermal Shutoff with Standard Output Modules

Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 119
Output Module Features Chapter 4
Thermal Shutoff with Standard Output Modules
Table 34 describes what happens when a thermal shutoff condition is detected
on Compact 5000 I/O standard output modules.
Table 35 describes what happens when the thermal shutoff condition is
corrected on Compact 5000 I/O standard output modules.
For more information on how to use the modules, see Appendix B, Module Tag
Definitions on page 231.
Table 34 - Thermal Shutoff - Compact 5000 I/O Standard Output Modules
Output Behavior Tag Value Diagnostic Value I/O Status Indicator
State
• Faults
• Turns off
I.Ptxx.ShortCircuit tag = 1 — Flashing red
Table 35 - Thermal Shutoff - Compact 5000 I/O Standard Output Modules
Output Behavior Tag Value Diagnostic Value I/O Status Indicator
State
Restarts in its
commanded state.
I.Ptxx.ShortCircuit tag = 0 — Turns off if there is no
longer a load that is
connected to the
output.
