Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 157
Configure a Standard Module Chapter 6
New Remote I/O Module
To use the New Module method with remote I/O modules, complete the
following steps.
1. Right-click the Compact 5000 I/O EtherNet/IP adapter and choose
New Module.
2. Select the module and click Create.
TIP This example shows how to add a remote I/O module when the Logix
Designer application project is offline.
You can add new modules when the project is online, if desired. In this case,
the steps are similar to the steps described in
Discover Remote I/O Modules
on page 155. One exception is that, in step 1, you choose New Module
instead of Discover Modules.
