Allen-Bradley Compact 5000 Series - Safety Input Module Status Indicators

Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 219
Troubleshoot Your Module Appendix A
Compact 5000 I/O Safety
Input Module
Status Indicators
Figure 26 shows the Compact 5000 I/O safety input module status indicators.
Figure 26 - Compact 5000 I/O Safety Input Module Status Indicators
5069-OBV8S
SIL2 CPU
5069-L3100ERMS2
Compact GuardLogix
5069-OBV8S
5069-IB8S5069-IB8S
OUTPUT OUTPUT
SA Power MOD Power
Safety Modules
5069-IB8S
Safety Input 0 (I00)
Safety Input 1 (I01)
Safety Input 2 (I02)
Safety Input 3 (I03)
Safety Input 4 (I04)
Safety Input 5 (I05)
Safety Input 6 (I06)
Safety Input 7 (I07)
Test Output 0 (TO0)
Test Output 0 (TO0)
Test Output 1 (TO1)
Test Output 1 (TO1)
Test Output/Muting Output 2 (TO2M)
Test Output/Muting Output 2 (T02M)
Test Output/Muting Output 3 (T03M)
Test Output/Muting Output 3 (T03M)
COM
COM
Module Status Indicator
I/O Status
Indicators
5069-IB8S, 5069-IB8SK
SA Status Indicator
IMPORTANT: The 5069-IB8SK module status indicators appear the same as the
indicators are shown on the 5069-IB8S module.
