Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 181

Configure a Standard Module Chapter 6

Time Sync Category

The Time Sync category displays and status information about the module

when the project is online. The Time Sync category displays the following

information:

• CIP Sync Time Synchronization

• UTC System Time

• Grandmaster Clock information

• Local Clock information
