Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 153
Configure a Standard Module Chapter 6
New Local I/O Modules
To use the New Module method with local I/O modules, complete the
following steps.
1. Right-click the 5069 Backplane and choose New Module.
2. At the Select Module Type window, click Create to add the discovered
module to your project.
TIP This example shows how to add a local I/O module when the Logix Designer
application project is offline.
You can add new modules when the project is online, if desired. In this case,
the steps are similar to the steps described in
Discover Local I/O Modules on
page 150. One exception is that, in step 1, you choose New Module instead
of Discover Modules.
