Chapter 2 Features Common to Compact 5000 I/O Digital Modules
Input Module Compatibility
Compact 5000 I/O digital input modules interface to sensing devices and
detect whether they are On or Off.
The input modules convert DC On/Off signals from user devices to
appropriate logic level for use in the controller. Typical input devices include
the following:
• Proximity switches
• Limit switches
• Selector switches
• Float switches
• Push-button switches
When you design systems with Compact 5000 I/O digital input modules,
consider the following factors:
• Voltage necessary for your application
• Current leakage
• Whether you need a solid-state device
• Whether your application uses sinking or sourcing wiring
