Chapter 4 Output Module Features
Isolated and Non-isolated
Varieties of Output Modules
The 5069-OW4I and 5069-OX4I standard output modules provide point-to-
point wiring isolation.
DC INPUT
5069-IB16
DC OUTPUT
5069-OB16
ANALOG INPUT
5069-IY4
SA Power MOD Power
ANALOG OUTPUT
5069-OF8
DC INPUT
5069-IB16
Standard Modules
™
NET B1
LINK B1
NET A1
LINK A1
NET A2
LINK A2
SPEED X1
LINK X1
OK
RUN
FORCE
FAN 1
SD
FAN 2
CompactLogix 5480
B1
A1
1
2
A2
5069-L46ERMW
CONTROLLER
UPS
MP
SA
R
B
F
R
B
F
DC INPUT
5069-IB16
DC OUTPUT
5069-OB16
ANALOG INPUT
5069-IY4
ANALOG OUTPUT
5069-OF8
DC INPUT
5069-IB16
IMPORTANT Although some Compact 5000 I/O digital output modules do not provide
wiring isolation, all Compact 5000 I/O digital output modules maintain
internal electrical isolation between the system-side and field-side power
buses.
