Module Tag Definitions Appendix B
5069-IB6F-3W Module Tags
This section describes the tags that are associated with the 5069-IB6F-3W
module.
Configuration Tags
Table 69 describes the 5069-IF6F-3W module configuration tags.
DC INPUT
5069-IB16
DC OUTPUT
5069-OB16
ANALOG INPUT
5069-IY4
SA Power MOD Power
ANALOG OUTPUT
5069-OF8
DC INPUT
5069-IB16
Standard Modules
Table 69 - 5069-IB6F-3W Configuration Tags
Name Size Definition Valid Values
Counterxx.InputOffOnFilter SINT The amount of time that a signal must be in the on state
before the input data indicates the on state. The amount
of time is indicated using an enumeration. Not all
products support all enumeration values.
• 5 = 0 μs
• 6 = 5 μs
• 7 = 10 μs
• 8 = 20 μs
• 9 = 50 μs
• 10 = 100 μs
• 11 = 200 μs
• 12 = 500 μs
• 13 = 1 ms
• 14 = 2 ms
• 15 = 5 ms
• 16 = 10 ms
• 17 = 20 ms
• 18 = 50 ms
Counterxx.InputOnOffFilter SINT The amount of time that a signal must be in the off state
before the input data indicates the off state. The amount
of time is indicated using an enumeration. Not all
products support all enumeration values.
• 5 = 0 μs
• 6 = 5 μs
• 7 = 10 μs
• 8 = 20 μs
• 9 = 50 μs
• 10 = 100 μs
• 11 = 200 μs
• 12 = 500 μs
• 13 = 1 ms
• 14 = 2 ms
• 15 = 5 ms
• 16 = 10 ms
• 17 = 20 ms
• 18 = 50 ms
Counterxx.RolloverAtPreset BOOL Determines whether the simple counter rolls over to 0
when it reaches O:Preset (1) or at 2147483647 (0).
• 0 = Maximum value
• 1 = Preset value
Ptxx.InputOffOnFilter SINT The amount of time that a signal must be in the on state
before the input data indicates the on state. The amount
of time is indicated using an enumeration. Not all
products support all enumeration values.
• 5 = 0 μs
• 6 = 5 μs
• 7 = 10 μs
• 8 = 20 μs
• 9 = 50 μs
• 10 = 100 μs
• 11 = 200 μs
• 12 = 500 μs
• 13 = 1 ms
• 14 = 2 ms
• 15 = 5 ms
• 16 = 10 ms
• 17 = 20 ms
• 18 = 50 ms
