Chapter 2 Features Common to Compact 5000 I/O Digital Modules
Fault and Status Reporting
The Compact 5000 I/O digital modules report fault and status data along with
channel data. Fault and status data is reported in the following ways:
• Logix Designer application
• Module status indicators
• I/O status indicators
For more information on fault and status reporting, see:
• Input modules -
Fault and Status Reporting on page 88
• Output modules -
Fault and Status Reporting on page 121
• Appendix A,
Troubleshoot Your Module on page 211
