Allen-Bradley Compact 5000 Series User Manual

Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 217
Troubleshoot Your Module Appendix A
Figure 25 - Compact 5000 I/O Standard Relay Output Module Status Indicators
RELAY OUTPUT
5069-OW4I
RELAY OUTPUT
5069-OW16
Module Status
Indicator
I/O Status
Indicators
5069-OW4I
Output Channel 0 (O00)
Output Channel 1 (O01)
Output Channel 2 (O02)
Output Channel 3 (O03)
0 A
0 B
1 A
1 B
2 A
2 B
3 A
3 B
Terminals
are unused
5069-OW16
Module Status
Indicator
I/O Status
Indicators
Output Channel 0 (O00)
Output Channel 1 (O01)
Output Channel 2 (O02)
Output Channel 3 (O03)
Output Channel 4 (O04)
Output Channel 5 (O05)
Output Channel 6 (O06)
Output Channel 7 (O07)
Output Channel 8 (O08)
Output Channel 9 (O09)
Output Channel 10 (O10)
Output Channel 11 (O11)
Output Channel 12 (O12)
Output Channel 13 (O13)
Output Channel 14 (O14)
Output Channel 15 (O15)
Common 0
Common 1
