Rockwell Automation Publication 1756-RM003N-EN-P - October 2011 513
Special Instructions (FBC, DDT, DTR, PID) Chapter 13
.BIAS REAL Feedforward or bias %
.MAXS REAL Maximum engineering unit scaling value
.MINS REAL Minimum engineering unit scaling value
.DB REAL Deadband engineering units
.SO REAL Set output %
.MAXO REAL Maximum output limit (% of output)
.MINO REAL Minimum output limit (% of output)
.UPD REAL Loop update time (seconds)
.PV REAL Scaled PV value
.ERR REAL Scaled error value
.OUT REAL Output %
.PVH REAL Process variable high alarm limit
.PVL REAL Process variable low alarm limit
.DVP REAL Positive deviation alarm limit
.DVN REAL Negative deviation alarm limit
.PVDB REAL Process variable alarm deadband
.DVDB REAL Deviation alarm deadband
.MAXI REAL Maximum PV value (unscaled input)
.MINI REAL Minimum PV value (unscaled input)
.TIE REAL Tieback value for manual control
.MAXCV REAL Maximum CV value (corresponding to 100%)
.MINCV REAL Minimum CV value (corresponding to 0%)
.MINTIE REAL Minimum tieback value (corresponding to 100%)
.MAXTIE REAL Maximum tieback value (corresponding to 0%)
Mnemonic: Data Type Description
