Allen-Bradley Logix5000 Reference Manual

Rockwell Automation Publication 1756-RM003N-EN-P - October 2011 201
Input/Output Instructions (MSG, GSV, SSV, IOT) Chapter 4
ControllerDevice Attributes
The ControllerDevice object identifies the physical hardware of the controller.
Attribute Data Type Instruction Description
DeviceName SINT[33] GSV ASCII string that identifies the catalog number of the controller and memory board. The first byte
contains a count of the number of ASCII characters returned in the array string.
ProductCode INT GSV Identifies the type of controller:
Value Meaning
15 SoftLogix5800
49 PowerFlex with DriveLogix5725
52 PowerFlex with DriveLogix5730
53 Emulator
54 1756-L61 ControlLogix
55 1756-L62 ControlLogix
56 1756-L63 ControlLogix
57 1756-L64 ControlLogix
64 1769-L31 CompactLogix
65 1769-L35E CompactLogix
67 1756-L61S GuardLogix
68 1756-L62S GuardLogix
69 1756-LSP GuardLogix
72 1768-L43 CompactLogix
74 1768-L45 CompactLogix
76 1769-L32C CompactLogix
77 1769-L32E CompactLogix
80 1769-L35CR CompactLogix
85 1756-L65 ControlLogix
86 1756-L63S GuardLogix
87 1769-L23E-QB1 CompactLogix
88 1769-L23-QBFC1 CompactLogix
89 1769-L23E-QBFC1 CompactLogix
ProductRev INT GSV Identifies the current product revision. Display should be hexadecimal. The low byte contains the
major revision; the high byte contains the minor revision.
SerialNumber DINT GSV Serial number of the device. The serial number is assigned when the device is built.
Status INT GSV Device Status BitsController Status Bits
7...4 Meaning13...12Meaning
0000 Reserved01Keyswitch in run
0001 Flash update in progress10Keyswitch in program
0010 Reserved11Keyswitch in remote
0011 Reserved
0100 Flash is bad15...14Meaning
0101 Faulted modes01Controller is changing modes
0110 Run10Debug mode if controller in run mode
0111 Program
Fault Status Bits
11...8 Meaning
0001 Recoverable minor fault
0010 Unrecoverable minor fault
0100 Recoverable major fault
1000 Unrecoverable major fault
Type INT GSV Identifies the device as a controller. Controller = 14.
Vendor INT GSV Identifies the vendor of the device. Allen-Bradley = 0001.
