Chapter 16 Math Conversion Instructions (DEG, RAD, TOD, FRD, TRN, TRUNC)
Description: The FRD instruction converts a BCD value (Source) to a decimal value and
stores the result in the Destination.
Arithmetic Status Flags: Arithmetic status flags are affected.
Fault Conditions: None
Execution:
Relay Ladder
Function Block
Condition Action
Prescan The rung-condition-out is set to false.
Rung-condition-in is false The rung-condition-out is set to false.
Rung-condition-in is true The controller converts the Source to a decimal value and places the result in the Destination.
The rung-condition-out is set to true.
Postscan The rung-condition-out is set to false.
Condition Action
Prescan No action taken.
Instruction first scan No action taken.
Instruction first run No action taken.
EnableIn is cleared EnableOut is cleared.
EnableIn is set The instruction executes.
EnableOut is set.
Postscan No action taken.
