Chapter 4 Input/Output Instructions (MSG, GSV, SSV, IOT)
Specify CIP Generic Messages
If you want to In this property Type or select
Perform a pulse test on a digital output
module
Message Type CIP Generic
Service Type Pulse Test
Source tag_name of type INT [5]
This array contains Description
tag_name[0] Bit mask of points to test (test only one point at a
time)
tag_name[1] Reserved, leave 0
tag_name[2] Pulse width (hundreds of μs, usually 20)
tag_name[3] Zero cross delay for ControlLogix I/O (hundreds of
μs, usually 40)
tag_name[4] Verify delay
Destination Blank
Get audit value Message Type CIP Generic
Service Type Audit Value Get
Source Element Cannot change this field, blank
Source Length Cannot change this field, set to 0 bytes
Destination Element This array contains Description
tag_name of type
DINT[2] or LINT
This tag contains the Audit Value for the
controller.
Note: We recommend using the DINT[2] data type
to avoid limitations when working with LINT data
types in Rockwell Automation controllers.
Get controller events monitored for changes
See Table 3
Message Type CIP Generic
Service Type Changes to Detect Get
Source Element Cannot change this field, blank
Source Length Cannot change this field, set to 0 bytes
Destination Element This array contains Description
tag_name of type
DINT[2] or LINT
This tag represents a bit mask of the changes
monitored for the controller.
Note: We recommend using the DINT[2] data type
to avoid limitations when working with LINT data
types in Rockwell Automation controllers.
Set controller events monitored for changes
See Table 3
Message Type CIP Generic
Service Type Changes to Detect Set
Source Element This array contains Description
tag_name of type
DINT[2] or LINT
This tag represents a bit mask of the changes
monitored for the controller.
Note: We recommend using the DINT[2] data type
to avoid limitations when working with LINT data
types in Rockwell Automation controllers.
Source Length Cannot change this field, set to 8 bytes
Destination Element Cannot change this field, blank
