Rockwell Automation Publication 20Y-TG001C-EN-P - April 2017 115

Connector Descriptions Appendix C

Figure 35 - Fiber-optic Cable Routing

H11H12H13 H8H9H10

X9X15

X3X4X5

H4H5H6 H1H2H3

X11

Seven

Fiber-optic

Cables

Six

Fiber-optic

Cables

Fiber-optic

Adapter Board

ASIC Board

Gate Driver Board

For ASIC board part number information, see

Table 15 on page 121

For gate driver board part number information, see

Table on page 119
