Allied Telesis AT-8000S Series User Manual

Configuring Device Security
Configuring Network Security
Page 47
Figure 27: Port Security Page
The Port Security Page displays the Zoom View of device ports. The possible port indicators are:
2. Select the ports to lock. The port indicator changes to selected.
3. Click Modify. The Port Security Configuration Page opens:
Port is not selected — Indicates that security is currently not enabled on the port.
Port is selected — Indicates that security is currently enabled on the port.

Allied Telesis AT-8000S Series Specifications

General

Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Humidity	5% to 95% non-condensing
Switching Capacity	104 Gbps
Forwarding Rate	77.4 Mpps
VLANs	4, 094
Layer 3 Features	Static routing, RIP v1/v2
Management	Web-based
Operating Humidity	10% to 90% non-condensing
