Configuring SNMP
Configuring SNMP Notifications
Page 123
The SNMP Notify Page contains tables for SNMPv2 and SNMP v3 notification recipients and lists the following
parameters:
SNMPv1,2c Notification Recipient
The SNMP v1, v2c Recipient table contains the following fields:
• Recipients IP — Displays the IP address to which the traps are sent.
• Notification Type — Displays the type of notification sent. The possible field values are:
– Trap — Indicates that traps are sent.
– Inform — Indicates that informs are sent.
• Community String — Displays the community string of the trap manager.
• Notification Version — Displays the trap type. The possible field values are:
– SNMP V1 — Indicates that SNMP Version 1 traps are sent.
– SNMP V2c — Indicates that SNMP Version 2 traps are sent.
• UDP Port — Displays the UDP port used to send notifications. The field range is 1-65535. The default is 162.
• Filter Name — Indicates if the SNMP filter for which the SNMP Notification filter is defined.
• Timeout — Indicates the amount of time (in seconds) the device waits before resending informs. The field
range is 1-300. The default is 15 seconds.
• Retries — Indicates the number of times the device resends an inform request. The field range is 1-255.
The default is 3.
SNMPv3 Notification Recipient
The SNMPv3 Notification Recipient table contains the following fields:
• Recipients IP — Displays the IP address to which the traps are sent.
• Notification Type — Displays the type of notification sent. The possible field values are:
– Trap — Indicates that traps are sent.
– Inform — Indicates that informs are sent.
• User Name — Displays the user to which SNMP notifications are sent.
• Security Level — Displays the means by which the packet is authenticated. The possible field values are:
– No Authentication — Indicates that the packet is neither authenticated nor encrypted.
– Authentication — Indicates that the packet is authenticated.
• UDP Port — Displays the UDP port used to send notifications. The field range is 1-65535. The default is 162.
• Filter Name — Includes or excludes SNMP filters.
• Timeout — Indicates the amount of time (in seconds) the device waits before resending informs. The field
range is 1-300. The default is 15 seconds.
• Retries — Indicates the number of times the device resends an inform request. The field range is 1-
255.The default is 3.
• Remove — Deletes the currently selected recipient. The possible field values are:
– Checked — Removes the selected recipient from the list of recipients.
– Unchecked — Maintains the list of recipients.
2. Click Create. The Create SNMP Notification Recipient Page opens:
