Allied Telesis AT-8000S Switch
Web Browser Interface User’s Guide
Defining MSTP Instances
Network administrators can assign MSTP settings to a specific instance (port or LAG) using the MSTP Instance
Settings Page.
To define MSTP interface settings:
1. Click Layer 2 > MSTP. The MSTP Page opens.
2. Click Configure next to the Configure Instance Settings option. The MSTP Instance Settings Page opens:
Figure 61: MSTP Instance Settings Page
The MSTP Interface Settings Page contains the following fields:
• VLAN — Displays the VLAN ID.
• Instance ID — Configures the MSTP instances. The possible field range is 0-7.
3. Map the VLANs to Instance IDs.
4. Click Save Config on the menu, to save changes permanently.
