63
English
Audio Processor
Operation
Turn the rotary switch clockwise or
counterclockwise to adjust to your desired level
upward or downward respectively.
When the adjustments have been completed,
press the rotary switch.
4
3
1
2
Display the DIV. cont. screen.
Press the FUNC button.
The contents of the Function Guide screen
changes.
Select the frequency range you want to adjust.
When the F2 (LEVEL) button is pressed once,
the display shows the adjustment value of the
level.
Each press changes the frequency ranges as
follows:
When only one divider is connected
→ L-Low → R-Low → F-High/L
R-High/R ← R-High/L ← F-High/R ←
When two dividers are connected
→ L-Low → R-Low → L-High → R-High
The Level adjustment mode is activated and the
"DN/RTN/UP" menu appears.
Adjusting Levels
FUNC
Divider
CONT.
X-OVER/
LEVEL/
T-CR/
P.UP
P.DOWN
C H STEP
Custom
PSET
vol. 35
RF
RF
-
12
-
12
-
12
-
12
-
12
-
12
dB
DN RTN UP
F-High/R
-12
dB
L
R
