86
English
Remote Control
(RUE-4160 supplied with CVA-1000E)
1
2
3
Opening the battery cover.
Push and slide the cover in the arrow direction,
and the cover will be removed.
Replacing the battery.
Remove the old batteries. Insert new ones
matching the (+) and (–) polarities as shown in
the diagram inside the unit.
Closing the cover.
Push the cover in the arrow direction until a
click is heard.
Replacing battery
Applicable battery: Use two "AAA" sized dry
batteries.
To Next Page
