C1n Series WIFI AP/CPE Web-admin Configuration Manual
TPS15-003_rev1.3
2) Thin AP
Show the status of thin AP function (On/Off).
When the thin AP function is On, We’ll see more information about AC:
AC IP Address: shows the AC IP address.
AC Association Status: shows the status of thin AP associate to AC.
AC IP Address(DHCP Option 43): shows the AC IP acquired from DHCP Option 43.
AC IP Address(DHCP Option 60): shows the AC IP acquired from DHCP Option 60.
AC Online Time: shows the AC online time.
3) Network (Switch/Gateway)
It shows the status and information of network. It is switch mode as default.
IPv4 DHCP Client: Whether C1n Series AP/CPE was configured as IPv4 DHCP client.
IPv4 Address: current IPv4 address
IPv4 Subnet Mask: IPv4 subnet mask
IPv4 Default Gateway Address: IPv4 gateway address
IPv4 DNS Server: IPv4 DNS Server
4) Interfaces (2)
- Ethernet
It shows the status and information of Ethernet including Mac address, Traffic (Tx/Rx),
Speed, Throughput (Tx/Rx), Duplex and Auto-negotiation. If click the “More>>”, more
detail information will be shown.
- Radio0 (2.4G) (for C1n & C1xn)
It shows Radio0 interface information including Operation Mode, Mac address, Traffic
(Tx/Rx), Wireless Mode, Throughput (Tx/Rx), Channel, Channel Usage(Busy%),Transmit
Power and Noise Level. If click the “More>>”, more detail information will be shown.
As default, the 2.4G radio is on.
- Radio0 (5G) (for C1an & C1xan)
It shows Radio0 interface information including Operation Mode, Mac address, Traffic
(Tx/Rx), Wireless Mode, Throughput (Tx/Rx), Channel, Channel Usage(Busy%),Transmit
Power and Noise Level. If click the “More>>”, more detail information will be shown.
As default, the 5G radio is off.
4.2. Interface
User may check the interface information of Radio0 and Ethernet via
StatusInterface.
