C1n Series WIFI AP/CPE Web-admin Configuration Manual
TPS15-003_rev1.3
Figure 4-2 Interface Status
4.2.1. Radio Interface Status
User may obtain the information about Radio0 interface via Status Interface
Radio0(2.4G or 5G). The information is shown with the corresponding radio mode
(AP/Station/Repeater), C1an and C1xan also have Bridge mode.
4.2.1.1. Radio0 Interface Status-AP Mode
When Radio0 work at AP mode, interface information includes following 5 parts:
Status, Statistic, Channel Usage, WLAN and Association List.
4.2.1.1.1. Status
User may obtain the current status of Radio0 interface via StatusInterfaceRadio0
Status. The parameters include Radio mode, Radio Enable, MAC Address, Country
Code, Radio Channel, Transmit Power, and Wireless Mode.
Figure 4-3 Radio0 Interface Status
