C1n Series WIFI AP/CPE Web-admin Configuration Manual
TPS15-003_rev1.3
Mode: Operation mode (AP)
Radio Enable: Radio0 status (ON/OFF)
MAC Address: Radio0 MAC address.
Country Code: The default country code is HONG KONG.
Radio Channel: Radio0 current channel
Transmit Power：Radio0 transmit power
Wireless Mode：Radio0 wireless mode
4.2.1.1.2. Statistic
User may collect Radio0 statistical information via StatusInterfaceRadio0
Statistic. The statistic includes Radio0 Tx and Rx Packets, Tx and Rx Packet Rate, Tx
and Rx total traffic, and Tx and Rx Throughput.
Figure 4-4 Radio0 Statistic Information
Packets： Radio0 received and sent packets.
Packet Rate：Radio0 packet rate.
Total Traffic： Radio0 received and sent total traffic.
Throughput：Radio0 throughput.
4.2.1.1.3. Channel Usage
User may obtain the Radio0 channel usage information via StatusInterfaceRadio0
Channel Usage. The Radio0 channel usage information includes Tx% (Avg), Rx%
(Avg), Busy% (Avg), Noise Floor(dBm), CTL0, CTL1, EXT0, EXT1, Interference Mitigation
Offset (0~50dB) , Traffic Distribution, Nearby AP List and Auto Refresh Interval.
