ALTAI C1N - Repeater Configuration; Wlan Configuration

Altai Technologies Ltd. All rights reserved
C1n Series WIFI AP/CPE Web-admin Configuration Manual
TPS15-003_rev1.3
5.4.1.3.2.1. Repeater Configuration
User may provide the remote AP’s information and configure the corresponding
security setting via ConfigurationWirelessRadio0WLAN, then click the “More…”
behind the WLAN 15 to access repeater setting page. The detail of repeater
configuration is as the same as that in “Station” mode. Please refer to section 5.4.1.2
Radio0 Configuration- Station Mode for more details.
Figure 5-48 Repeater Mode - WLAN15 Setting
5.4.1.3.2.2. WLAN Configuration
Maximum 15 WLAN can be configured as access point in “Repeater” mode, the
detail of repeater configuration is as the same as that in “AP” mode. User may specify
the WLAN setting via ConfigurationWirelessRadio0WLAN to click the “More…”
behind the WLANs. Please refer to section Radio0 General configuration- AP Mode for
more details.
