C1n Series WIFI AP/CPE Web-admin Configuration Manual
TPS15-003_rev1.3
Radio Mode: Operation mode of C1n Series AP/CPE
Country Code: Specify country that C1n locates. This setting is related about radio
regulatory domain, such as maximum transmission power, available operating
frequency channel … etc. Hong Kong is default setting.
Transmit Power: Specify the maximum transmission power (dBm) of C1n for radio0.
Maximum Clients: Specify the maximum number of users C1n serves.
Enable Inter-WLAN User Isolation: Allow or block inter-WLAN user communication. If
enabled, clients cannot communicate to each other directly when they associated
into different WLAN. By default, it is “disable”.
Signal Level (SNR) Indicators: There are 6 LEDs at the back of the C1n, 4 LEDs are used
for signal strength indication in Station mode for association with another AP. The 4
LEDs altogether shall display 8 levels of signal strength, in the following manner.
Signal level
PWR
LAN
SS1
SS2
SS3
SS4
1(Weakest)
Blink
Off
Off
Off
2
On
Off
Off
Off
3
On
Blink
Off
Off
4
On
On
Off
Off
5
On
On
Blink
Off
6
On
On
On
Off
7
On
On
On
Blink
8
On
On
On
On
Configure C1n as wireless relay station (i.e. “Repeater” Mode):
1. Select ConfigurationWirelessRadio0
2. Enable radio by clicking Enable Radio
3. Select “Repeater” in Radio Mode
4. Select your country code in Country Code
5. Set maximum transmit power in Transmit Power
6. Set the maximum number of users A2 serves in Maximum Clients
7. Check Enable Inter-WLAN User Isolation if necessary.
8. Set the desired SNR value in Signal Level (SNR) Indicators .
9. Click Submit
10. Click Save&Apply to apply
5.4.1.3.2. WLAN Configuration
