Altai Technologies Ltd. All rights reserved
C1n Series WIFI AP/CPE Web-admin Configuration Manual
TPS15-003_rev1.3
Figure 4-8 Radio0 Association List
Total Client Association: Total number of associated clients in Radio0
Client Association Histogram: Association client history records
STA ID: Wireless client’s ID
MAC Address: Wireless client’s MAC address
IP Address: Wireless client’s IP address
WLAN ID: WLAN ID that wireless clients associated
SNR: Wireless client’s SNR (Uplink)
Throughput STA (Tx/Rx): Wireless client’s actual throughput (kbps)
Traffic STA (Tx/Rx): Wireless clients download and upload traffic (Bytes)
Data Rate STA (Tx/Rx): Wireless clients download and upload rate (Mbps)
Click this icon , below prompt will pop up. If choice OK, the associated client will
be disconnected and added into rogue station list.
Figure 4-9 Add Client to Rogue Station List
Click the “View Histograms” user can see SNR Histogram and Tx/Rx Rate
Histogram.
