showt: Specify Whether shows the accounting radius server’s secret information.
Configure a WLAN with either WPA/WPA2/WPA-auto security:
1. Select ConfigurationWirelessRadio0WLAN to edit “More…” behind the
WLAN, and then select WLAN Security to access to security configuration page.
2. Select “WPA”, “WPA2” or “WPA-auto” in Authentication Mode.
3. Select suitable cipher mode in Cipher Mode. If Authentication Mode is set as
“WPA2”, “AES” is the only option. If Authentication Mode is set as “WPA-auto”,
“AES+TKIP” is the only option.
4. Specify update time of group key in Group Key Update Interval. The default
value is 86400s
5. Specify network access server’s ID in NAS Identifier if necessary.
6. Specify connection timeout in RADIUS Retry Timeout. The default value is 300s
7. Set Radius server IP address in Radius Server
8. Set Radius server port in Radius Port
9. Set Radius secret in Radius Secret
10. Set Secondary Radius server IP address in Secondary Radius Server if
necessary
11. set Secondary Radius server port in Secondary Radius Port if necessary
12. set Secondary Radius server secret in Secondary Radius Secret if necessary
13. Specify accounting interim interval in Accounting interim interval. The default
value is 300s
14. Set Radius accounting server IP address in Radius Accounting Server
15. Set Radius accounting server port in Radius Accounting Port
16. Set Radius accounting secret in Radius Accounting Secret
17. Set Secondary Radius accounting server IP address in Secondary Radius
Accounting Server if necessary
18. set Secondary Radius accounting server port in Secondary Radius Accounting
Port if necessary
19. set Secondary Radius accounting server secret in Secondary Radius
Accounting Secret if necessary
20. Click Submit
21. Click Save&Apply to apply
NOTE: TKIP causes bad performance on 802.11n network.
